Transverse 400 Series Hall Probe Specifications

Click here for Hall probe active areas

By default, each probe has a 2 m long cable (except for Model 410 and cryogenic probes). Also available: 6 m, 10 m, and 30 m lengths.

Transverse probes

Operating temperature range: 0 °C to +75 °C

L mm (in)

T mm (in)

W mm (in)

A mm (in)

Active area mm (in)

Stem material

Frequency range

Usable full scale ranges

Corrected accuracy (% rdg at 25 °C)

Temp coefficient (max) zero

Temp coefficient (max) of sensitivity

Contains temp sensor

for Models 475, 455, and 425

HMMT-6J02-VR

No

50.8 ±3.2 (2 ±0.125)

1.55 (0.061) max

4.57 ±0.13 (0.180 ±0.005)

3.81 ±1.27 (0.150 ±0.050)

Approx 1.02 dia (0.040 dia)

Aluminum

DC to 800 Hz

HSE 3.5 G, 35 G, 350 G, 3.5 kG, 35 kG

±0.20% to 30 kG and ±0.25% 30 to 35 kG

±0.09 G/°C

455/475: ±0.015%/°C 425: -0.04%/°C

Yes

HMMT-6J04-VR

Yes

101.6 ±3.2 (4 ±0.125)

HMMT-6J08-VR

No

203.2 ±3.2 (8 ±0.125)

HMMT-6J12-VR

No

305 ±6.4 (12 ±0.25)

HMMT-6J18-VR

No

457 ±6.4 (18 ±0.25)

HMNT-4E02-VR

No

50.8 ±3.2 (2 ±0.125)

1.14 (0.045) max

3.81 ±0.13 (0.150 ±0.005)

Fiberglass epoxy

DC to 20 kHz

HMNT-4E04-VR

Yes

101.6 ±3.2 (4 ±0.125)

HMMT-6J02-VF

No

50.8 ±3.2 (2 ±0.125)

1.55 (0.061) max

4.57 ±0.13 (0.180 ±0.005)

Aluminum

DC to 400 Hz

HST-4 35 G, 350 G, 3.5 kG, 35 kG

±0.10% to 30 kG and ±0.15% 30 to 35 kG

±0.13 G/°C

-0.005%/°C

HMMT-6J04-VF

Yes

101.6 ±3.2 (4 ±0.125)

HMMT-6J08-VF

No

203.2 ±3.2 (8 ±0.125)

HMMT-6J12-VF

No

305 ±6.4 (12 ±0.25)

HMMT-6J18-VF

No

457 ±6.4 (18 ±0.25)

HMNT-4E02-VF

No

50.8 ±3.2 (2 ±0.125)

1.14 (0.045) max

3.81 ±0.13 (0.150 ±0.005)

Fiberglass epoxy

DC to 800 Hz

HMNT-4E04-VF

Yes

101.6 ±3.2 (4 ±0.125)

L mm (in)

T mm (in)

W mm (in)

A mm (in)

Active area mm (in)

Stem material

Frequency range

Usable full scale ranges

Corrected accuracy (% rdg at 25 °C)

Temp coefficient (max) zero

Temp coefficient (max) of sensitivity

Contains temp sensor

for Models 460, 450, and 421

MMT-6J02-VH

No

50.8 ±3.2 (2 ±0.125)

1.55 (0.061) max

4.57 ±0.13 (0.180 ±0.005)

3.81 ±1.27 (0.150 ±0.050)

Approx 1.02 dia (0.040 dia)

Aluminum

DC and 10 Hz to 100 Hz

HSE-1 30 G, 300 G, 3 kG, 30 kG

±0.25% to 30 kG

±0.09 G/°C

450/460: ±0.015%/°C 421: -0.04%/°C

Yes

MMT-6J04-VH

101.6 ±3.2 (4 ±0.125)

MMT-6J08-VH

203.2 ±3.2 (8 ±0.125)

MMT-6J12-VH

305 ±6.4 (12 ±0.25)

MMT-6J18-VH

457 ±6.4 (18 ±0.25)

MNT-4E02-VH

50.8 ±3.2 (2 ±0.125)

1.14 (0.045) max

3.81 ±0.13 (0.150 ±0.005)

Fiberglass epoxy

DC and 10 Hz to 400 Hz

MNT-4E04-VH

101.6 ±3.2 (4 ±0.125)

MMT-6J02-VG

50.8 ±3.2 (2 ±0.125)

1.55 (0.061) max

4.57 ±0.13 (0.180 ±0.005)

Aluminum

DC

HST-2 300 G, 3 kG, 30 kG

±0.15% to 30 kG

±0.13 G/°C

-0.005%/°C

No

MMT-6J04-VG

101.6 ±3.2 (4 ±0.125)

MMT-6J08-VG

203.2 ±3.2 (8 ±0.125)

MMT-6J12-VG

305 ±6.4 (12 ±0.25)

MMT-6J18-VG

457 ±6.4 (18 ±0.25)

MNT-4E02-VG

50.8 ±3.2 (2 ±0.125)

1.14 (0.045) max

3.81 ±0.13 (0.150 ±0.005)

Fiberglass epoxy

DC to 10 Hz to 400 Hz

MNT-4E04-VG

101.6±3.2 (4±0.125)

Transverse probes for cryogenic applications

L mm (in)

D mm (in)

A mm (in)

Active area mm (in)

Stem material

Frequency range

Usable full scale ranges

Corrected accuracy (% rdg at 25 °C)

Operating temp range

Temp coefficient (max) zero

Temp error (approx) calibration

Contains temp sensor

for Models 475, 455, and 425

300 K

ref

HMCT-3160-WN

No

1549 ±25.4 (61 ±1)

6.35 dia ±0.25 (0.25 dia ±0.010)

5.33 ±1.27 (0.210 ±0.050)

Approx 1 dia (0.040 dia)

Stainless steel

DC to 800 Hz

HST-3 35 G, 350 G, 3.5 kG, 35 kG, 350 kG

±2% to 100 kG

1.5 K to 350 K

±0.13 G/°C

200 K

+0.05%

No

100 K

-0.04%

80 K

-0.09%

for Models 460, 450, and 421

20 K

-0.40%

MCT-3160-WN

No

1549 ±25.4 (61 ±1)

6.35 dia ±0.25 (0.25 dia ±0.010)

5.33 ±1.27 (0.210 ±0.050)

Approx 1 dia (0.040 dia)

Stainless steel

DC and 10 Hz to 400 Hz

HST-1 300 G, 3 kG, 30 kG, 300 kG

±2% to 100 kG

1.5 K to 350 K

±0.13 G/°C

4 K

-0.70%

No

1.5 K

-1.05%
