Search Coils /technical-specifications
Product Overview
Technical Specifications
ORDER Now!
Downloads
Specifications
FNT-6R04-100
FNT-5P04-30
Calibration accuracy
0.25%
0.35%
Area-turns (approx)
100 cm
2
30 cm
2
Coil resistance (approx)
6.5 Ω
110 Ω
Average coil diameter
1.04 cm
0.39 cm
Operating temperature range
0 ºC to 60 ºC
Input resistance (fluxmeter)
10 kΩ
100 kΩ
10 kΩ
100 kΩ
DC ranges
30 mVs (3 T)
3 mVs (300 mT)
300 mVs (30 T)
30 mVs (3 T)
30 mVs (10 T)
3 mVs (1 T)
300 mVs (100 T)
30 mVs (10 T)
